Coordinate Measuring Machine (CMM)

Coordinate Measuring Machine (CMM)

3-D Coordinate Measuring Machine, Model "Spectra"
Make: Accurate lndia.
Operation- CNC

Measuring Range :
  • X axis: 500mm
  • Y axis: 600mm
  • Z axis: 400mm
Features :

Proven design with all granite construction for stable performance, Wrap around air bearing construction for high acceleration and stability. Zero hysteresis belt drive for smooth repeatable movement. X& Z axis guide ways made hollow reducing mass to achieve high acceleration. In built Y axis for better homogeneity of material. High resolution Reader Head for better accuracy.


Workpiece weight (kg) 500
Accuracy MPEE (as per ISO 10360 – 2 with in µm) 1.5 + L / 350
Resolution (in µm) 0.1 / 0.5
Guidance Air bearings on all axes
Linear Velocity 400 mm/s
Volumetric Velocity 700 mm/s
Measuring table (Material) Granite
Probing option TP 20, TP200, SP 25M, SP 80, Laser Scanner, PH 20, PH 20MT, Revo
